Machinery Use PU Urethane Round Belting With Rough Surface

Cina Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikasi
Cina Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikasi
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

I 'm Online Chat Now

Machinery Use PU Urethane Round Belting With Rough Surface

Machinery Use PU Urethane Round Belting With Rough Surface
Machinery Use PU Urethane Round Belting With Rough Surface Machinery Use PU Urethane Round Belting With Rough Surface Machinery Use PU Urethane Round Belting With Rough Surface

Gambar besar :  Machinery Use PU Urethane Round Belting With Rough Surface

Detail produk:
Place of Origin: china
Nama merek: jiuna
Sertifikasi: ROHS
Model Number: Diameter 2mm-20mm
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100.000 meters per Month
Detil Deskripsi produk
kekerasan: 85A warna: hijau
Kisaran suhu: -35 C- 80º C Jenis: Sabuk bundar PU
bahan: PU Permukaan: kasar
Cahaya Tinggi:

pu sabuk diekstrusi

,

sabuk bundar hijau

,

Belting Bulat Uretan Permukaan Kasar



Machinery Use PU Urethane Round Belting With Rough Surface



 Pu Round Belt



Temperature range -35°C - 80°C
Shore A hardness range 80A - 98A
With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
Round Belt:
Round Belt Dia. is from 2mm to 30mm



Applications:
--------------------------------------------------------------------------------
PU Rubber Round Belt is widely used in transmission and distribution of the following industry.

--- Newspaper conveying,
--- Packing machines,
--- Ceramic and stoneware processing plants, such as glazing Lines, transmission lines, polishing line etc.
--- Floor and roof tiles conveying,
--- Wood Working machineries,
--- Textile machines,
--- Paper industry machines,
--- Food grading machines, other food processing machines.

Features:
--------------------------------------------------------------------------------
PU Rubber Round Belt has many advantages as follow: Is widely used in transmission and distribution products for the textile, clothing, food, packaging, printing, machinery, electronic, glass, chemicals, automobiles, beverages, furniture, toys, paper and other industries; Especially in the following industry.


1) Outstanding abrasion resistance
2) High tensile and tear strength
3) Resistance to oils, fuels, and oxygen
4) Fabulous weatherability and high impact resistance
5) Low compression set
--------------------------------------------------------------------------------







Products introduction:





Urethane round belts are elastomeric belts for power transmission application.

Having most metric sizes (2mm to 20mm) and standard O-ring sizes.

Polyether and Polyurethane round belts have best resilience of any elastic material.

Polyester product has good wear resistance, its wear resistance is 3.5 times of common plastic

and rubber.





Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30





Service commitment:



“  Quality for keeping going ,Credit to win the world  ”

Machinery Use PU Urethane Round Belting With Rough Surface 0Machinery Use PU Urethane Round Belting With Rough Surface 1Machinery Use PU Urethane Round Belting With Rough Surface 2Machinery Use PU Urethane Round Belting With Rough Surface 3
