Flexure resistant 2mm - 20mm 100% pu round belt For packing

Cina Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikasi
Cina Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikasi
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

I 'm Online Chat Now

Flexure resistant 2mm - 20mm 100% pu round belt For packing

large.img.alt
small.img.alt small.img.alt small.img.alt small.img.alt

Gambar besar :  Flexure resistant 2mm - 20mm 100% pu round belt For packing

Detail produk:
Place of Origin: China
Nama merek: Jiuna
Sertifikasi: ROHS
Model Number: Diameter 2mm~20mm
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 96.000 meters per Month
Detil Deskripsi produk
Hardness: 85 shore A Color: Dark Green
Material: PU length: 30m/roll
stretching rete: 1.5-3% type: PU round belt
Cahaya Tinggi:

sabuk bundar pu

,

sabuk bundar hijau

,

85 pantai Sabuk poliuretan bundar hijau

Flexure resistant 2mm - 20mm 100% pu round belt For packing



PU Cord Belt Application :


 1.   Widely used in textile
 2.   printing and packing machine
 3.   food & beverage processing
 4.   wood processing
 5.   paper processing
 6.   electronic
 7.   post service
 8.   tobacco transmission line
 9.   Wall floor tile conveying industrial line
10.  Ceramic industry line or polishing line
PU  Round Belt(smooth/rough)
(1)Thermoplastic polyurethane material, easy to be melted jointed,100% pure polyurethane
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35℃ - 80℃
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics.
 Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and
other industries, especially in the ceramic industry, widely used in the facilities line the glaze,
 polishing lines, and transmission line.
(6) Dia. is from 2mm to 30mm. Smooth Belt with good surface finish; Rough belt with even surface roughness.
They are used widely.

Items No. φ

least radius of gyration

stretch rate

Maximum tensile rate

Hardness

length of rolled

DIA

(mm)

In

mm

Stretching rate

Kg

Lbs

Hardness

(A)

Roll

(m)

2mm

0.79

20

1.5-3%

0.3

0.7

90

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

85

200

5mm

1.57

40

1.5-3%

2.0

4.3

85

100

6mm

1.97

50

1.5-3%

3.2

7.0

85

100

7mm

2.17

55

1.5-3%

4.1

9.0

85

100

8mm

2.56

65

1.5-3%

5.0

11.0

85

100

9mm

2.95

75

1.5-3%

6.8

15.0

85

50

10mm

2.95

75

1.5-3%

7.7

17.0

85

50

12mm

3.94

100

1.5-3%

12.2

27.0

85

30

15mm

4.72

120

1.5-3%

17.7

39.0

85

30

18mm

5.71

145

1.5-3%

25.4

56.0

85

30

20mm

6.30

160

1.5-3%

31.3

69.0

85

30



Flexure resistant  2mm - 20mm 100% pu round belt For packing 0Flexure resistant  2mm - 20mm 100% pu round belt For packing 1
