Hardness 85A-90APU Round Belt Polyurethane Round Belt Transmission Belt Textile Machines

Gambar besar : Hardness 85A-90APU Round Belt Polyurethane Round Belt Transmission Belt Textile Machines

Detail produk:

Place of Origin:	wuxi city of china
Nama merek:	jiuna
Sertifikasi:	ROHS
Model Number:	dia8 mm

Syarat-syarat pembayaran & pengiriman:

Minimum Order Quantity:	10 rolls
Packaging Details:	Inner packing is plastic film .outer packing is carton
Delivery Time:	Within 7 working days After receipt of your deposit
Payment Terms:	T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability:	96.000 meters per Month

Kontak

Detil Deskripsi produk

hardness:	85A	stretching rate:	1.5-3%
material:	PU	color:	green
length:	30m/roll	Type:	PU round belt
pre-tensioning:	1.5%-3%
Cahaya Tinggi:	pu round belt , sabuk putaran hijau

Green Polyurethane Round Belt PaIndustrial Transmission Conveyor

PU rough Round Belt(smooth/rough)

(1)Thermoplastic polyurethane material, easy to be melted jointed,100% pure polyurethane

(2)Reinforced by Polyester Cord or Steel Cord

(3)Temperature range -35℃ - 80℃

(4)Shore A hardness range 80A - 98A

(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.

(6) Dia. is from 2mm to 30mm. Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.

Features:
Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:
Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.

Items NO.Φ	Least radius of gyration		Stretching rate	Maximum tensile rate		Hardness	Length of rolled
DIA(mm)	In	mm	%	Kg	Lbs	Shore( A)	Length of rolled
2mm	0.79	20	1.5-3%	0.3	0.7	95	400
2.5mm	0.87	22	1.5-3%	0.4	0.9	95	400
3mm	0.98	25	1.5-3%	0.7	1.6	90	400
3.5mm	1.18	30	1.5-3%	0.95	2.1	90	400
4mm	1.38	35	1.5-3%	1.2	2.7	90	200
5mm	1.57	40	1.5-3%	2.0	4.3	90	100
6mm	1.97	50	1.5-3%	3.2	7.0	90	100
7mm	2.17	55	1.5-3%	4.1	9.0	90	100
8mm	2.56	65	1.5-3%	5.0	11.0	90	100
9mm	2.95	75	1.5-3%	6.8	15.0	90	50
10mm	2.95	75	1.5-3%	7.7	17.0	90	50
12mm	3.94	100	1.5-3%	12.2	27.0	90	30
15mm	4.72	120	1.5-3%	17.7	39.0	90	30
18mm	5.71	145	1.5-3%	25.4	56.0	90	30
20mm	6.30	160	1.5-3%	31.3	69.0	90	30
