Diameter 2mm - 20mm Polyurethane Round Belt With Wear - Resistance , 90a Hardness

Cina Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikasi
Cina Wuxi Jiunai Polyurethane Products Co., Ltd Sertifikasi
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

I 'm Online Chat Now

Diameter 2mm - 20mm Polyurethane Round Belt With Wear - Resistance , 90a Hardness

Diameter 2mm - 20mm Polyurethane Round Belt  With Wear - Resistance , 90a Hardness
Diameter 2mm - 20mm Polyurethane Round Belt  With Wear - Resistance , 90a Hardness Diameter 2mm - 20mm Polyurethane Round Belt  With Wear - Resistance , 90a Hardness Diameter 2mm - 20mm Polyurethane Round Belt  With Wear - Resistance , 90a Hardness Diameter 2mm - 20mm Polyurethane Round Belt  With Wear - Resistance , 90a Hardness

Gambar besar :  Diameter 2mm - 20mm Polyurethane Round Belt With Wear - Resistance , 90a Hardness

Detail produk:
Place of Origin: China
Nama merek: Jiuna
Sertifikasi: ROHS
Model Number: Diameter 2 ~20 mm
Syarat-syarat pembayaran & pengiriman:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 7 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment
Supply Ability: 96.000 meters per Month
Factory: wuxi city
Export port: shanghai
Detil Deskripsi produk
material: PU ,TPU type: PU round belt
surface: smooth hardness: 90A
Standard or Nonstandard: Standard heat-resistant: -30 ℃~+80℃
Cahaya Tinggi:

pu round belt

,

sabuk putaran hijau

Diameter 2mm - 20mm Polyurethane Round Belt  With Wear - Resistance , 90a Hardness
Polyurethane Round Belt
Features:
1) made of PU material, easy to be joint at high heat.
2) Available to add nylon cord or steel cord
3) Tolerant temperturer: -35℃--80℃
4) High capacity on wear-resistance, flexibity. Wildly applied in varies industries such as textile, package, printing, machinery, electricity electronics, glass,ceramics, ESPECIALLY in ceramic/marble, they are welcome in the polishing& glazing .
5) Round belt:
   a:  diameter: 2mm--30mm
   b:  surface: vivid

Polyurethane belting of introduction:
Special color round belt can be custom-made ,
Yellow and blue pearl round belt applied to sports leisure fitness industrial like skipping rope.
Urethane round belts are elastomeric belts for power transmission application.
Having most metric sizes (2mm to 20mm) and standard O-ring sizes.
Polyether and Polyurethane round belts have best resilience of any elastic material.Polyester product




Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled
 ( m )

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30


Service commitment:
“Quality for keeping going ,Credit to win the world”
